1、项目背景

**经常在使用paddle的时候发现常用的对抗训练基础工具有待开源补充，本项目基于常见的对抗训练论文进行代码复现，应该是目前飞桨社区最全的对抗训练合集，如果觉得本项目对您有用，请动动小手Fork、Star鼓励一下！

2、项目介绍

对抗训练是一种引入噪声的训练方式，可以对参数进行正则化，提升模型鲁棒性和泛化能力。
有监督数据下使用交叉熵作为损失：

半监督数据下使用KL散度作为损失：

扰动如何得来呢？这需要对抗的思想，即往增大损失的方向增加扰动
有监督数据下：

半监督数据下：

θ上面一个尖儿代表的是常数，r代表的当前输入计算出来的梯度，r_adv是对抗训练计算出来的梯度。目的是说在计算对抗扰动时虽然计算了梯度，但不对参数进行更新，因为当前得到的对抗扰动是对旧参数最优的。

用一句话形容对抗训练的思路，就是在输入上进行梯度上升(增大loss)，在参数上进行梯度下降(减小loss)。由于输入会进行embedding lookup，所以实际的做法是在embedding table上进行梯度上升。

接下来介绍不同的方法，后续方法优化的主要方向有两点：得到更优的扰动 & 提升训练速度。

3、对抗论文

FGSM (Fast Gradient Sign Method）：ICLR2015
FGM (Fast Gradient Method）：ICLR2017
PGD (Projected Gradient Descent）：ICLR2018
FreeAT (Free Adversarial Training）：NIPS2019
YOPO (You Only Propagate Once）：NIPS2019
AWP（Adversarial Weight Perturbation Helps Robust Generalization）：NIPS 2020

导入环境

import paddle
from paddle import nn

FGSM (Fast Gradient Sign Method）：ICLR2015

FGSM是Goodfellow提出对抗训练时的方法，假设对于输入的梯度为：

那扰动肯定是沿着梯度的方向往损失函数的极大值走：

用老太太打架形容：跟着你的方向前进，步步逼人，你来我往

class FGSM:
    def __init__(self, model: nn.Module, eps=0.1):
        self.model = (model.module if hasattr(model, "module") else model)
        self.eps = eps
        self.backup = {}

    # only attack word embedding
    def attack(self, emb_name='embedding'):
        for name, param in self.model.named_parameters():
            if param.requires_grad and emb_name in name:
                self.backup[name] = param.data.clone()
                r_at = self.eps * param.grad.sign()
                param.data.add_(r_at)

    def restore(self, emb_name='embedding'):
        for name, para in self.model.named_parameters():
            if para.requires_grad and emb_name in name:
                assert name in self.backup
                para.data = self.backup[name]

        self.backup = {}

# 对应第一步
optimizer = paddle.optimizer.AdamW(learning_rate=5e-5, parameters=model.parameters())
fgsm = FGSM(model=model)

for batch in dataloader:
    # 对应第二步
    loss = model(batch)
    loss.backward()
    # 对应第三步
    fgsm.asttack()
    # 对应第四步
    loss_adv = model(batch)
    loss_adv.backward()
    # 对应第五步
    fgsm.restore()
    # 对应第六步
    optimizer.step()
    optimizer.clear_grad()

FGM (Fast Gradient Method）：ICLR2017

Goodfellow后续提出的FGM则是根据具体的梯度进行scale，得到更好的对抗样本：

用老太太打架形容：在限定规矩范围内，见招学招，你来我往

class FGM:
    def __init__(self, model: nn.Module, eps=1.):
        self.model = (model.module if hasattr(model, "module") else model)
        self.eps = eps
        self.backup = {}

    # only attack embedding
    def attack(self, emb_name='embedding'):
        for name, param in self.model.named_parameters():
            if param.requires_grad and emb_name in name:
                self.backup[name] = param.data.clone()
                norm = paddle.norm(param.grad)
                if norm and not paddle.isnan(norm):
                    r_at = self.eps * param.grad / norm
                    param.data.add_(r_at)

    def restore(self, emb_name='embedding'):
        for name, para in self.model.named_parameters():
            if para.requires_grad and emb_name in name:
                assert name in self.backup
                para.data = self.backup[name]

        self.backup = {}

# 对应第一步
optimizer = paddle.optimizer.AdamW(learning_rate=5e-5, parameters=model.parameters())
fgm = FGM(model=model)

for batch in dataloader:
    # 对应第二步
    loss = model(batch)
    loss.backward()
    # 对应第三步
    fgm.attack()
    # 对应第四步
    loss_adv = model(batch)
    loss_adv.backward()
    # 对应第五步
    fgm.restore()
    # 对应第六步
    optimizer.step()
    optimizer.clear_grad()

PGD (Projected Gradient Descent）：ICLR2018

FGM简单粗暴的“一步到位”，可能走不到约束内的最优点。PGD则是“小步走，多走几步”，如果走出了扰动半径为epsilon的空间，就映射回“球面”上，以保证扰动不要过大

用老太太打架形容：让你没有机会出手，一来多回，小步多走

class PGD:
    def __init__(self, model, eps=1., alpha=0.3):
        self.model = (model.module if hasattr(model, "module") else model)
        self.eps = eps
        self.alpha = alpha
        self.emb_backup = {}
        self.grad_backup = {}

    def attack(self, emb_name='embedding', is_first_attack=False):
        for name, param in self.model.named_parameters():
            if param.requires_grad and emb_name in name:
                if is_first_attack:
                    self.emb_backup[name] = param.data.clone()
                norm = paddle.norm(param.grad)
                if norm != 0 and not paddle.isnan(norm):
                    r_at = self.alpha * param.grad / norm
                    param.data.add_(r_at)
                    param.data = self.project(name, param.data)

    def restore(self, emb_name='embedding'):
        for name, param in self.model.named_parameters():
            if param.requires_grad and emb_name in name:
                assert name in self.emb_backup
                param.data = self.emb_backup[name]
        self.emb_backup = {}

    def project(self, param_name, param_data):
        r = param_data - self.emb_backup[param_name]
        if paddle.norm(r) > self.eps:
            r = self.eps * r / paddle.norm(r)
        return self.emb_backup[param_name] + r

    def backup_grad(self):
        for name, param in self.model.named_parameters():
            if param.requires_grad and param.grad is not None:
                self.grad_backup[name] = param.grad.clone()

    def restore_grad(self):
        for name, param in self.model.named_parameters():
            if param.requires_grad and param.grad is not None:
                param.grad = self.grad_backup[name]

# 对应第一步
optimizer = paddle.optimizer.AdamW(learning_rate=5e-5, parameters=model.parameters())
pgd = PGD(model=model)

for batch in dataloader:
	# 对应第二步
	loss = model(batch)
	loss.backward()
    # 对应第三步
	pgd.backup_grad()
    # 对应第四步
	for k in range(pgd_k):
		pgd.attack(is_first_attack=(k == 0))
		if k != pgd_k - 1:
			model.zero_grad()
		else:
			pgd.restore_grad()
		loss_adv = model(batch)
		loss_adv.backward()
    # 对应第五步
	pgd.restore()
    # 对应第六步
	optimizer.step()
	optimizer.clear_grad()

FreeAT (Free Adversarial Training）：NIPS2019

FreeAT的思想是在对每个样本x连续重复m次训练，计算r时复用上一步的梯度，为了保证速度，整体epoch会除以m。r的更新公式为：

class FreeAT:
    def __init__(self, model, eps=0.1):
        self.model = (model.module if hasattr(model, "module") else model)
        self.eps = eps
        self.emb_backup = {}
        self.grad_backup = {}
        self.last_r_at = 0

    def attack(self, emb_name='embedding', is_first_attack=False):
        for name, param in self.model.named_parameters():
            if param.requires_grad and emb_name in name:
                if is_first_attack:
                    self.emb_backup[name] = param.data.clone()
                param.data.add_(self.last_r_at)
                param.data = self.project(name, param.data)
                self.last_r_at = self.last_r_at + self.eps * param.grad.sign()

    def restore(self, emb_name='embedding'):
        for name, param in self.model.named_parameters():
            if param.requires_grad and emb_name in name:
                assert name in self.emb_backup
                param.data = self.emb_backup[name]
        self.emb_backup = {}

    def project(self, param_name, param_data):
        r = param_data - self.emb_backup[param_name]
        if paddle.norm(r) > self.eps:
            r = self.eps * r / paddle.norm(r)
        return self.emb_backup[param_name] + r

    def backup_grad(self):
        for name, param in self.model.named_parameters():
            if param.requires_grad and param.grad is not None:
                self.grad_backup[name] = param.grad.clone()

    def restore_grad(self):
        for name, param in self.model.named_parameters():
            if param.requires_grad and param.grad is not None:
                param.grad = self.grad_backup[name]

YOPO (You Only Propagate Once）：NIPS2019

极大值原理PMP(Pontryagin’s maximum principle)是optimizer的一种，它将神经网络看作动力学系统。这个方法的优点是在优化网络参数时，层之间是解藕的。通过这个思想，我们可以想到，既然扰动是加在embedding层的，为什么每次还要计算完整的前后向传播呢？基于这个想法，作者想复用后几层的梯度。
假设p为定值：

则对r的更新就可以变为

class YOPO:
    def __init__(self, eps= 6/255.0, sigma=3/255.0, nb_iter=20,
                 norm=np.inf, DEVICE=paddle.device('cpu'),
                 mean=paddle.tensor(np.array([0]).astype(np.float32)[np.newaxis, :, np.newaxis, np.newaxis]),
                 std=paddle.tensor(np.array([1.0]).astype(np.float32)[np.newaxis, :, np.newaxis, np.newaxis]), random_start=True):
        '''
        :param eps: maximum distortion of adversarial examples
        :param sigma: single step size
        :param nb_iter: number of attack iterations
        :param norm: which norm to bound the perturbations
        '''
        self.eps = eps
        self.sigma = sigma
        self.nb_iter = nb_iter
        self.norm = norm
        self.criterion = nn.CrossEntropyLoss().to(DEVICE)
        self.DEVICE = DEVICE
        self._mean = mean.to(DEVICE)
        self._std = std.to(DEVICE)
        self.random_start = random_start

    def single_attack(self, net, inp, label, eta, target = None):
        '''
        Given the original image and the perturbation computed so far, computes
        a new perturbation.
        :param net:
        :param inp: original image
        :param label:
        :param eta: perturbation computed so far
        :return: a new perturbation
        '''

        adv_inp = inp + eta

        #net.zero_grad()

        pred = net(adv_inp)
        if target is not None:
            targets = paddle.sum(pred[:, target])
            grad_sign = paddle.autograd.grad(targets, adv_in, only_inputs=True, retain_graph = False)[0].sign()

        else:
            loss = self.criterion(pred, label)
            grad_sign = paddle.autograd.grad(loss, adv_inp,
                                            only_inputs=True, retain_graph = False)[0].sign()

        adv_inp = adv_inp + grad_sign * (self.sigma / self._std)
        tmp_adv_inp = adv_inp * self._std +  self._mean

        tmp_inp = inp * self._std + self._mean
        tmp_adv_inp = paddle.clamp(tmp_adv_inp, 0, 1) ## clip into 0-1
        #tmp_adv_inp = (tmp_adv_inp - self._mean) / self._std
        tmp_eta = tmp_adv_inp - tmp_inp
        tmp_eta = clip_eta(tmp_eta, norm=self.norm, eps=self.eps, DEVICE=self.DEVICE)

        eta = tmp_eta/ self._std

        return eta

    def attack(self, net, inp, label, target = None):

        if self.random_start:
            eta = paddle.FloatTensor(*inp.shape).uniform_(-self.eps, self.eps)
        else:
            eta = paddle.zeros_like(inp)
        eta = eta.to(self.DEVICE)
        eta = (eta - self._mean) / self._std
        net.eval()

        inp.requires_grad = True
        eta.requires_grad = True
        for i in range(self.nb_iter):
            eta = self.single_attack(net, inp, label, eta, target)
            #print(i)

        #print(eta.max())
        adv_inp = inp + eta
        tmp_adv_inp = adv_inp * self._std +  self._mean
        tmp_adv_inp = paddle.clamp(tmp_adv_inp, 0, 1)
        adv_inp = (tmp_adv_inp - self._mean) / self._std

        return adv_inp

    def to(self, device):
        self.DEVICE = device
        self._mean = self._mean.to(device)
        self._std = self._std.to(device)
        self.criterion = self.criterion.to(device)

AWP（Adversarial Weight Perturbation Helps Robust Generalization）：NIPS 2020

class AWP:
    def __init__(
        self,
        model,
        optimizer,
        adv_param=['weight'],
        adv_lr=1,
        adv_eps=0.001,
        adv_step=1,
        scaler=None
    ):
        self.model = model
        self.optimizer = optimizer
        self.adv_param = adv_param
        self.adv_lr = adv_lr
        self.adv_eps = adv_eps
        self.adv_step = adv_step
        self.backup = {}
        self.backup_eps = {}
        self.scaler = scaler

    def attack_backward(self, batch):
        if (self.adv_lr == 0):
            return None

        self._save()
        for i in range(self.adv_step):
            self._attack_step()
            loss = self.model(batch)
            self.optimizer.zero_grad()
            self.scaler.scale(loss).backward()
        self._restore()

    def _attack_step(self):
        e = 1e-6
        for name, param in self.model.named_parameters():
            if (param.requires_grad) and (param.grad is not None) and (self.adv_param[0] in name):
                norm1 = paddle.norm(param.grad)
                norm2 = paddle.norm(param.data.detach())
                if norm1 != 0 and not paddle.isnan(norm1):
                    r_at = self.adv_lr * param.grad / (norm1 + e) * (norm2 + e)
                    param.data.add_(r_at)
                    param.data = paddle.min(
                        paddle.max(param.data, self.backup_eps[name][0]), self.backup_eps[name][1]
                    )
                # param.data.clamp_(*self.backup_eps[name])

    def _save(self):
        for name, param in self.model.named_parameters():
            if (param.requires_grad) and (param.grad is not None) and (self.adv_param[0] in name):
                if name not in self.backup:
                    self.backup[name] = param.data.clone()
                    grad_eps = self.adv_eps * param.abs().detach()
                    self.backup_eps[name] = (
                        self.backup[name] - grad_eps,
                        self.backup[name] + grad_eps,
                    )

    def _restore(self,):
        for name, param in self.model.named_parameters():
            if name in self.backup:
                param.data = self.backup[name]
        self.backup = {}
        self.backup_eps = {}

4、项目总结

1、在深度学习项目、竞赛中对抗训练是必不可少的增强工具，现在完善了飞桨此处的分支，可以更加愉快的使用了。

2、fgsm、fgm、pgd是最常使用的增强工具，所以还附加了使用逻辑，其余的增强工具只是完成了核心代码的复现。

5、引用资料

1、Explaining and Harnessing Adversarial Examples
2、Adversarial Training for Free!
3、Adversarial Training Methods for Semi-Supervised Text Classification
4、You Only Propagate Once: Accelerating Adversarial Training via Maximal Principle
5、综述】NLP 对抗训练
6、一文搞懂NLP中的对抗训练
7、加速对抗训练——YOPO算法浅析
8、炼丹技巧 功守道：NLP中的对抗训练
9、<EYD与机器学习>：对抗攻击基础知识

文章仅为搬运，原作链接：https://aistudio.baidu.com/aistudio/projectdetail/4327353
